June 2013
FL7701
Smart LED Lamp Driver IC with PFC Function
Features
Description
?
?
?
?
?
?
?
?
Digitally Implemented Active PFC Function
(No Additional Circuit Necessary for High PF)
Built-in HV Supplying Circuit: Self Biasing
Application Input Range: 80 V AC ~ 308 V AC
AOCP Function with Auto-Restart Mode
Built-in Over-Temperature Protection Function
Cycle-by-Cycle Current Limit
Current-Sense Pin Open Protection
Low Operating Current: 0.85 mA (Typical)
The FL7701 LED lamp driver is a simple IC with PFC
function. The special “ adopted digital ” technique of the
IC can automatically detect input voltage condition and
send an internal reference signal for achieving high
power factor. When AC input is applied to the IC, PFC
function is automatically enabled. Otherwise, when DC
input is applied to the IC, PFC function is automatically
disabled. The FL7701 does not need a bulk capacitor
(electrolytic capacitor) for supply rail stability, which can
significantly affect to LED lamp system.
Related Resources
?
?
?
?
?
?
Under-Voltage Lockout with 5 V Hysteresis
Programmable Oscillation Frequency
Programmable LED Current
Analog Dimming Function
Soft-Start Function
Precise Internal Reference: ±3%
?
Evaluation Board: FEBFL7701_L30U003A
Applications
?
?
LED Lamp for Decorative Lighting
LED Lamp for Low-Power Lighting
Ordering Information
Part Number
FL7701MX
Operating
Temperature Range
-40°C to +125°C
Package
8-Lead, Small Outline Integrated Circuit (SOIC),
JEDEC MS-012, .150-inch Narrow Body
Packing Method
Tape & Reel
? 2011 Fairchild Semiconductor Corporation
FL7701 ? Rev. 1.0.4
www.fairchildsemi.com
